KSEM390R3WD40M
Produktnummer: 6123742
EAN: 4056544456618
Salgsenhet: STK
inkl. mva.
KSEM390R3WD40M
"GRUNDKOERPER, 3XD, DIAMETER=39.0MM"
| [D] Shank Diameter | 40.0000 |
| Kennametal | |
|---|---|
| ISO Catalog Number | KSEM390R3WD40M |
| [D1MAX] Drill Dia Max Metric | 40 |
| [L1] Gage Length | 175 |
| [L4/D1] Length/Diameter Ratio | 3 |
| [SSC] Insert/Blade Seat Size | 10 |
| [L] Overall Length | 243 |
| [D] Adapter Shank Bore Dia | 40 |
| [D1] Drill Diameter Min | 39 |
| [L3] Flute Length | 165 |
| [L4] Max. Drill Depth | 117 |
| [L5] Drill Point Length | 6.9 |
| [LS] Shank Length | 68 |
| Spesifikasjoner | |
|---|---|
| Vekt | 1.809 kg |
| Type | KROPP |
| Bordiameter | 39 mm |
| Bortype | KSEM |
| Borelengde | 3XD |
