DFPR120R2WB20M
Produktnummer: 7034765
Salgsenhet: STK
inkl. mva.
DFPR120R2WB20M
INDEX. DRILL-FIX-PRO DIA 12 MM 2XD WB
| Kennametal | |
|---|---|
| ISO Catalog Number | DFPR120R2WB20M |
| [CS] Coolant Supply Size | 1/8-27 NPT |
| [D1MAX] Drill Dia Max Metric | 12.5 |
| [L1] Gage Length | 45 |
| [D] Adapter Shank Bore Dia | 20 |
| [D1] Drill Diameter Min | 12 |
| [L4] Max. Drill Depth | 24 |
| [L5] Drill Point Length | 0.32 |
| [LS] Shank Length | 50 |
| Spesifikasjoner | |
|---|---|
| Vekt | 0.1817 kg |
| Type | KROPP |
| Bordiameter | 12 mm |
| Bortype | DFPR |
| Borelengde | 2XD |
