BETEX FLEXIBLE INDUCTOR 22KW, 20M¹, Ø12MM, MAX.180
Disse 22 kW-induktorene er egnet for bruk med 22 kW MF-generatoren. Fleksible induktorer kan plasseres i eller rundt arbeidsstykket. Magnetiske holdere for å feste induktoren er tilgjengelig som tilbehør.
|
Min. winding diameter flexible inductors 3.5kW |
|||
|
Length m |
Max. temp. |
Diameter cable |
Min. winding diameter |
|
5/7.5/10 |
180°C |
Ø 12 mm |
ca. 90 mm |
|
Min. winding diameter flexible inductors 10kW |
|||
|
Length m |
Max. temp. |
Diameter cable |
Min. winding diameter |
|
15/20/25/30 |
180°C |
Ø 12 mm |
ca. 75 mm |
|
15/20/25/30/35 |
180°C |
Ø 15 mm |
ca. 100 mm |
|
15/20/25/30/35 |
300°C |
Ø 20 mm |
ca. 120 mm |
|
Min. winding diameter flexible inductors 22kW |
|||
|
Length m |
Max. temp. |
Diameter cable |
Min. winding diameter |
|
15/20/25/30 |
180°C |
Ø 12 mm |
ca. 75 mm |
|
15/20/25/30 |
180°C |
Ø 15 mm |
ca. 100 mm |
|
15/20/25/30 |
300°C |
Ø 20 mm |
ca. 120 mm |
Min. winding diameter flexible inductors 44kW
|
Length m |
Max. temp. |
Diameter cable |
Min. winding diameter |
|
15/20/25/30 |
180°C |
Ø 19 mm |
ca. 140 mm |
|
15/20/25/30 |
300°C |
Ø 28 mm |
ca. 220 mm |
| Spesifikasjoner | |
|---|---|
| Vekt | 10 kg |
| Volum | 10 liter |
| kW | 22 |
